SPECIFICATIONS
|
FRAME
Bold Linkin 135 / Carbon HMX FORK
RockShox Pike Select RC Air REAR SHOCK
RockShox Deluxe Select RL3 Trunnion REMOTE SYSTEM
TracLoc Technology REAR DERAILLEUR
SRAM GX Eagle 12 Speed SHIFTERS
SRAM GX Eagle Trigger CRANKSET
SRAM GX Eagle DUB BB-SET
SRAM DUB PF 92 MTB Wide / shell 41x92mm CHAIN
SRAM CN GX Eagle CASSETTE
SRAM GX XG1275 / 10-52 T BRAKES
Shimano SLX M7120 4 Piston Disc ROTOR
Shimano SM-RT76 / 6 Bolt / 203/F and 180/R |
HANDLEBAR
Syncros Hixon 1.5 Alloy 7050 H’STEM
Syncros AM 1.5 SEATPOST
Syncros Duncan Dropper Post 1.5 34.9mm SEAT
Syncros Tofino 2.0 Regular HEADSET
Syncros – Acros Angle adjust & Cable Routing HS System WHEELSET
Syncros Revelstoke 2.0 6 Bolt FRONT TIRE
Maxxis Dissector / 2.4″ / 60TPI Foldable REAR TIRE
Maxxis Dissector / 2.4″ / 60TPI Foldable EXTRAS
Save the Day Kit ACCESSORIES
Syncros Eco Sealant APPROX WEIGHT IN KGS
13.9kg / 14.3kg |
FEATURES
For the most passionate riders seeking the most progressively engineered bikes, the all-new LINKIN provides the industry’s most sophisticated, state-of-the-art technology and design features.
MULTI TOOLTo get you back on the trail fast, the Syncros MATCHBOX SL-CT Multi-Tool is hidden inside the frame covering most adjustments. There when you need it. |
REAR AXLE TOOLThe bike is equipped with a rear axle tool which features a T25, T30 and a 6 mm allen key all in one. With these three options you can adjust all pivot hardware and nearly everything else there is to adjust on the bicycle. |
DROPPER POSTIncredible dropper post compatibility and unlimited positioning possibilities thanks to the horizontal layout of the rear shock in combination with the Internal Suspension Technology. Meaning a 200mm travel dropper coupled with a slammed seat position is no problem for the LINKIN. |
CHAIN MANAGEMENTThe bike also features chain management with an upper chainstay & seatstay protection and a chain guide to protect your bike and to keep things nice and quiet. |
TECHNOLOGIES
With the goal to create the best ride quality in combination with a clean, integrated design, Bold has discarded the principles of classic full-suspension frame design. Bold has redefined the traditional linkage systems to suit their frame’s kinematics and suspension characteristics by integrating the rear suspension into the frame design.
INTERNAL SUSPENSION TECHNOLOGYFrame stiffness, lowest center of gravity and optimum shock performance are the key benefits to our Internal Suspension Technology. The condition of the rear shock has a significant impact on suspension performance. The shock is always protected from dirt, water and crashes to ensure it is functioning at its best. As a result, the bike benefits from better handling, longer shock service intervals and a more stable, confidence inspiring ride. |
|
IST VPWith the shock placed internally, we are able to design an ultra-compact linkage system for low weight and high stiffness. The linkage is directly attached to the shock and mounted to an axle inside the frame, meaning the suspension pivots no longer must be constructed around the frame. This makes our link shorter than any other traditional suspension platform. Using a Virtual Pivot linkage design improves the suspension feel, pedaling, and braking response to work with maximum efficiency. Our kinematic suspension curve gives supple small bump sensitivity and, therefore, exceptional traction characteristics, excellent support in the mid-stroke, and a controlled deep stroke for perfect bottom-out control. |
|
REAR SHOCKThe LINKIN comes with either a FOX or ROCK SHOX shock option unlocking 150 mm or 135 mm of travel, both options featuring our patented NUDE Technology. Accessible mid-ride through the TracLoc System, the NUDE Technology enables an air volume adjustment to effect dynamic travel, making it the most innovative air shock on the market. Accessing the shock is possible via a cover in the down tube area. This makes it easy to adjust rebound, compression, and shock pressure as well as access the cable of the TracLoc Suspension System. Shock bolts are easily accessible from the outside. |
|
SHOCK LINKAGEThe LINKIN is available in 150 mm travel, as well as a sportier version with 135 mm of rear wheel travel. The travel options can be set by replacing the Shock Linkage at the bottom bracket without having to need to switch to a different shock. The different Shock Linkage gives the LINKIN the flexibility to have both travel options in one frame platform. TRAVEL INDICATORSetting the right Sag can easily be done via a magnet-equipped travel indicator on the outside. The end stroke travel can also be checked on the smartly designed travel indicator for perfect bottom-out control. |
|
TRACLOCTracLoc manages the Sag effect in several ways. Whereas most systems only increase low-speed compression in an effort to gain pedaling efficiency, TracLoc allows you to change not only compression damping but also to change the spring curve, dynamically altering the geometry of the bike. In Traction Mode, the shock is not only firmer, but it has dynamically less travel. The bike sits higher, maintains a steep seat angle for those climbs, and becomes more agile. In addition, the LINKIN has a Lockout Mode for going up the steepest trails in the most efficient manner possible. |
|
FLIP CHIPHaving the ability to tune the bottom bracket height and head angle allows you to optimize the geometry and handling for you and your trails. With the Flip Chip on the BOLD Variotec you can change the bottom bracket height by +/- 6.3 mm while changing the head angle by +/- 0.4 degrees, giving the LINKIN frame the availability to be customized off-the-shelf. |
|
HEAD ANGLE ADJUSTYou can adjust the head angle by effective +/- 1.0 degree slacker or steeper. This can be done by rotating the headset cups 180 degrees. |
GEOMETRY
Progressive geometry in combination with the innovative Internal Suspension Technology brings the perfect mix of balance and control to the LINKIN.
The shock is mounted in the lowest possible position inside the front triangle thanks to this design. This central and low mounting point for the shock, rocker link and pivot, but also the bottle cage lead to a very low center of mass, giving superb handling capabilities.
