-30%

CAMPAGNOLO Wheelset Shamal Ultra Disc

Original price was: $1,559.00.Current price is: $1,099.00. SGD

Now Campagnolo have taken their know how and expertise to introduce the new disc brake version. The result is a wheel already famous for its steering, smoothness and, versatility that is now also available for those wanting a bike with disc brakes.

SKU: WH19-SH2DFRX Category: Tags: ,

CHARACTERISTICS

– Disc brake variant of the famous Shamal Ultra aluminum wheel
– Flanges of the alloy hub and carbon fibre spacer in the front
– Front hub axle HH 12/100 and rear HH12/142 floating axle
– New “road” design of the flange: offering excellent integration with the AFS rotor, it improves transmission of the braking forces
– 2-Way Fit™ version
– Black self-locking anodized nipples add a touch of class and keep the spokes in place

TECHNICAL SPECIFICATIONS

  • 1,592 g (Two-way Fit)
  • FRONT WHEEL SPOKES: 14 aerodynamic aluminum spokes on the braking side and 7 aerodynamic aluminum spokes with a 2/1,6/2 mm section on the drivetrain side.
  • REAR WHEEL SPOKES: 7 aerodynamic aluminum spokes on the braking side and 14 aerodynamic aluminum spokes on the drivetrain side to ensure aerodynamics and response, transferring to the drivetrain side the braking torque generated on the disc.
  • ANODIZED SELF-LOCKING BLACK NIPPLES: Prevents the possible rotation of the spokes during the wheels’ life-cycle.
  • FRONT HH 12/100 AND REAR HH 12/142 FLOATING AXLE: only one specification to obtain the “Campagnolo performance” also in the transfer of forces to the frame. QR axles available as accessories.
  • USB (ULTRA SMOOTH BEARING): high quality ceramic bearings for a smooth and frictionless rolling. RING NUT WITH MICRO-ADJUSTMENT: it allows a precise adjustment of the hub.
  • ALUMINIUM SOLID BODY WITH MEGA-G3 SYSTEM IN THE REAR HUB: it ensures great efficiency in terms of aerodynamics and response thanks to the reinforced braking side to improve the resistance to the torque in the braking phase.
  • FRONT HUB ALLOY FLANGES AND CARBON FIBER SPACER: the result is a front wheel extremely light and robust. New “road” design of the flange: excellent integration with the AFS disc, it improves the transmission of the braking forces.
  • 2-WAY FIT VERSION (tubeless + clincher): it makes it possible for the cyclist to use the same rim to choose the best of the two worlds: traditional clincher tire or the innovative tubeless.
  • 17 mm INNER WIDTH RIM: it creates a perfect balance between weight and performance with 25 mm tires to achieve high levels of comfort.
  • DIFFERENT HEIGHT FOR THE FRONT RIM: The 27 mm profile on the front rim ensures the maximum rigidity on the point of contact of the nipples. The toroidal milling makes it possible to obtain a 25 mm height in the areas where no additional material is needed, reducing thus the weight and improving wheel rideability.
  • DIFFERENT HEIGHT FOR THE REAR RIM: the 30 mm profile on the rear rim ensures the maximum rigidity on the point of contact of the nipples. The toroidal milling makes it possible to obtain a 27 mm height in the areas where no additional material is needed, reducing thus the weight and improving the wheel response.
  • The Shamal Ultra C17 Disc wheel is entirely hand-assembled by a specialised Campagnolo® technician and is 100% checked by electronic instrumentation. This procedure ensures that every single Campagnolo® wheel offers maximum performance and reliability.

Comes with:

  • Magnet holder for aluminium spokes and rubber 24
  • Magnet 5×15 for aluminium spokes
  • Key for fastening the tubeless valve
  • Lever for assembling / disassembling the tyre
  • Magnet for nipples insertion

TECHNOLOGIES

2-WAY FIT™
DYNAMIC BALANCE™
MOMAG™
G3 SPOKE GEOMETRY

2-WAY FIT™ is the innovative profile that lets you fit either a tubeless tire or a classic clincher.

2-WAY FIT™

The concept is as simple as it is genius: balancing the weight of the rim joint with a mass of identical weight on the opposite side of the rim.

DYNAMIC BALANCE™

An absolute genius of a magnet. It is the tried and tested, patented “Mounting Magnet” system: MoMag™ for short.

MOMAG™

Campagnolo’s iconic G3 geometry challenges the conventional configuration of wheel spokes on racing bikes. Groups of three parallel straight-pull spokes are in fact arranged in a ratio of 2:1.

G3 SPOKE GEOMETRY

Brand

Campagnolo

Wheel Brake Type

Disc brake

Wheel Rim Depth

24mm

Wheel Rim Material

Alloy

Wheel Freewheel Body

Campagnolo, Shimano (HG11), SRAM (XDR)
