SCOTT Bike Scale Jr 24″ Disc blue

The SCOTT Scale 24 Disc is our truly functional bike for kids who like to race. With suspension and disc brakes this bike is made for kids who have a need for speed.

• FRAME

  Scale 24 Disc Junior
  Alloy 6061 / Semi int. HT
  SCOTT dropout / IS

• FORK

  SR Suntour XCT-JR 24 Disc
  50mm travel
  Softer spring setup

• REAR DERAILLEUR

  Shimano RD-TX800 Tourney
  8 Speed

• SHIFTERS

  Shimano SL-RS45-8R
  Revo Shifter

• CRANKSET

  Prowheel / Alloy Crank 140mm
  32T / w/CG PVG double cover

• BB-SET

  Feimin / BB68 / cartridge / square taper

• CHAIN

  KMC Z8.3

• CASSETTE

  SunRace CSM55
  8 Speed / 11-34T

• BRAKE LEVERS

  Tektro TS325A

• BRAKES

  Tektro SCM-02
  Mech. Disc Brake / 160mm rotor

• HANDLEBAR

  Junior Flat-Bar Alloy
  560mm / Syncros Youth 100/80 Grip

• H’STEM

  LEADTEC LCS-7130
  50mm / 25.4mm clamp

• SEATPOST

  Alloy 26.8x300mm

• SEAT

  Syncros Future Pro

• HEADSET

  Feimin FP-H807, 1 1/8″ Semi Int.

• HUB (FRONT)

  Formula DC-19-F / QR

• HUB (REAR)

  Formula DC-25-8-R / QR

• SPOKES

  15G / UCP / black

• RIMS

  Alex C-1000 Disc

• FRONT TIRE

  Kenda K1227 Booster / 24×2.2″ / 30TPI

• REAR TIRE

  Kenda K1227 Booster / 24×2.2″ / 30TPI

• PEDALS

  MARWI SP-700 / w/Reflector

• EXTRAS

  Kickstand

• ACCESSORIES

  Syncros Stem Protector

• APPROX WEIGHTS IN KG

  12

• APPROX WEIGHTS IN LBS

  26.46

• MAX. SYSTEM WEIGHT

  50 kg
  The overall weight includes the bike, the rider, the equipment, and possible additional luggage.

SIZE CHART

Please note that bike specifications are subject to change without prior notice.
