CHARACTERISTICS
Hyperon is the new Campagnolo wheel designed for the most refined and demanding cyclists.
A carbon wheel for racing bikes that embodies true Campagnolo product perfection: the result of the unparalleled success of the new line of ultra-light, high-performance wheels inaugurated with Hyperon Ultra to expand the range to top road bikes. The ideal choice for those who want to fully enjoy the cutting-edge technologies developed by our engineers, with the support of the most expert testers and feedback from pro cyclists.
The result is a less extreme wheel than Hyperon Ultra with a perfect mix of characteristics: lightweight construction, unequalled reactivity and superior ease of handling.
With the Hyperon range, we have taken H.U.L.C. molding technology and C-LUX finish to the next level to make it easy on the eye and light on the scales.
With an inner width of 21 mm and rim profile of 37 mm, Hyperon is a wheel that adapts to the needs of even the most demanding cyclist while enhancing the looks of any bike.
The rims on the new Hyperon are molded with the latest Campagnolo H.U.L.C. technology, the result of over 25 years of carbon molding experience. This technology ensures dimensional optimisation of the rims and the carbon fibre and resin ratio, which all contributes to increased stiffness and resistance.
The mirror-like C-LUX finish creates a surface so flawlessly smooth that it doesn’t require lacquer, saving weight. The scientific precision of C-LUX also helps to ensure the safest possible seating of tubeless tires, increasing the pressure seal, ease of installation/uninstallation, and reducing the risk of abrasions to the bead.
The Head-2-Bay system guarantees high precision head-to-bay coupling and the hub has been optimized to prevent inelastic spoke shearing. This innovative technology introduces a hi-load management system to reduce the risk of damage, guaranteeing perfectly balanced spoke tension and correct transfer of power to the road.
Our N3W Light freewheel body is designed to house 11-, 12- and 13-speed cassettes with 9-, 10- and 11-tooth starting sprockets. Extreme smoothness of the CULT bearings and maximum torsional stiffness, together with even lighter design offer ultimate control.
The rear rim profile is asymmetric for super stiffness control and total tension management, in order to guarantee maximum safety and handling around every bend.
The Campagnolo single-joint rim construction reduces potential points of weakness by having a solo fuse-point, down from the industry standard 4 joints. This enables the rim to be extremely stiff and, when combined with the aerospace-grade carbon material, incredibly hardwearing and resistant to damage.
TECHNICAL SPECIFICATIONS
- 1,340 g
- 21 circular-section slim steel spokes on the front in a two-cross pattern
- 24 circular-section slim steel spokes on the rear in a two-cross pattern
- Monolithic hub in Black Aluminum
- Cup/Cone Bearings
- Hub edges: 100 mm front, 142 mm rear
- Axle material: aluminum
- Profile height: 37 mm
- Material used for rim: Carbon
- Rim section (height/width): 37/ 26.7 mm
- Internal rim width: 21 mm
- Water Transfer Graphics
- Tyre compatibility: 2-way fit – Clincher with inner tube / Tubeless compatible
- The HYPERON Disc Brake Wheel is completely hand assembled by a Campagnolo® specialist and is 100% checked using electronic instrumentation. This procedure guarantees the maximum performance and reliability of every single Campagnolo® wheel.
- 50 mm Tubeless valve
- Valve reducer bushing
- 2 levers in composite for tire removal
- User manual
- Padded wheel bags
- Accessory sack
